| 产品图片 | 系列 | 输出频率 | 输出方式 | 输出数量 | 输入方式 | 工作电压 | 工作温度 | 抖动 | 产品特点 | 样品申请 | 规格书 |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DC~1GHz@LP-HCSL
DC~350MHz@LVCMOS |
LP_HCSL
LVCMOS |
8路差分
1路单端 |
3 Input Reference (Two Differential@DC~1Ghz/ One crystal@8~50Mhz)
|
1.8V~3.3V
|
-40°C~+85°C
|
34fs Typ. RMS(12KHz~20MHz)@156.25MHz LP_HCSL
|
Supports LP-HCSL differential outputs only; Ultra-low jitter and high PSRR (−76dBc)
|
|
||
|
|
DC~1GHz@LP-HCSL
DC~350MHz@LVCMOS |
LP_HCSL
LVCMOS |
8路差分
1路单端 |
3 Input Reference (Two Differential@DC~1Ghz/ One crystal@8~50Mhz)
|
1.8V~3.3V
|
-40°C~+85°C
|
34fs Typ. RMS(12KHz~20MHz)@156.25MHz LP_HCSL
|
Glitch-Free Switchover; Supports LP-HCSL differential outputs only; Ultra-low jitter and high PSRR (−76dBc)
|
|
||
|
DC~3.1GHz
|
LVDS
LVPECL LPHCSL LVCMOS |
8路差分
1路单端 |
3Input Reference (Two Differential@DC~3.1Ghz/ One crystal@8~50Mhz)
|
1.8V~3.3V
|
-40°C~+85°C
|
34fs Typ. RMS(12KHz ~ 20MHz)@156.25MHz LP_HCSL
|
Ultra-low additive jitter and output skew (<50ps)
|
|
||
|
|
DC~3.1GHz
|
LVDS
LVPECL LPHCSL LVCMOS |
8路差分
1路单端 |
3Input Reference (Two Differential@DC~3.1Ghz/ One crystal@8~50Mhz)
|
1.8V~3.3V
|
-40°C~+85°C
|
34fs Typ. RMS(12KHz ~ 20MHz)@156.25MHz LP_HCSL
|
Glitch-Free Switchover; Ultra-low additive jitter and output skew (<50ps)
|
|
||
|
1~333.33MHz
|
LPHCSL LVDS HCSL LVCMOS
|
2 differential-pair outputs
1 LVCMOS clock outputs |
Internal Crystal : 50Mhz
|
1.8V~3.3V
|
-40℃~+85℃
|
236fs Typ. RMS(12KHz~20MHz)@156.25MHz
|
Low power consumption: <100mw
@1.8V 100Mhz LP-HCSL outputs |
|
||
|
1~333.33MHz
|
LPHCSL LVDS HCSL LVCMOS
|
2 differential-pair outputs
1 LVCMOS clock outputs |
External Crystal : 8~50MHz
1.22MHz~250MHz |
1.8V~3.3V
|
-40℃~+85℃
|
236fs Typ. RMS(12KHz~20MHz)@156.25MHz
|
Low power consumption: <100mw
@1.8V 100Mhz LP-HCSL outputs |
|
||
|
1~333.33MHz
|
LPHCSL LVDS HCSL LVCMOS
|
1 differential-pair outputs
1 LVCMOS clock outputs |
Internal Crystal : 50Mhz
|
1.8V~3.3V
|
-40℃~+85℃
|
236fs Typ. RMS(12KHz~20MHz)@156.25MHz
|
Low power consumption: <100mw
@1.8V 100Mhz LP-HCSL outputs |
|
||
|
1~333.33MHz
|
LPHCSL LVDS HCSL LVCMOS
|
1 differential-pair outputs
1 LVCMOS clock outputs |
External Crystal : 8~50MHz
1.22MHz~250MHz |
1.8V~3.3V
|
-40℃~+85℃
|
236fs Typ. RMS(12KHz~20MHz)@156.25MHz
|
Low power consumption: <100mw
@1.8V 100Mhz LP-HCSL outputs |
|
||
|
DC~350MHz
|
LVCMOS
|
5
|
1 Input Reference (Differential/ Single-ended)
|
1.8V~3.3V
|
-40℃~+85℃
|
34 fs RMS (12kHz to 20MHz) typical @LVCMOS 156.25MHz
|
Ultra-low latency and skew
|
|
||
|
|
DC~350MHz
|
LVCMOS
|
5
|
1 Input Reference (Differential/ Single-ended)
|
1.8V~3.3V
|
-40℃~+85℃
|
34 fs RMS (12kHz to 20MHz) typical @LVCMOS 156.25MHz
|
Glitch-Free Switchover Ultra-low latency and skew
|
|
||
|
DC~350MHz
|
LVCMOS
|
10
|
3 Input Reference (Two Differential
@DC~350Mhz/ One crystal@8~50Mhz) |
1.8V~3.3V
|
-40℃~+85℃
|
34 fs RMS (12kHz to 20MHz) typical
@LVCMOS 156.25MHz |
Ultra-low latency and skew
|
|
||
|
DC~3.1GHz
|
LVDS
LVPECL LPHCSL LVCMOS |
10路差分
1路单端 |
LVDS
LVPECL LPHCSL LVCMOS 外部XTAL: 8~50MHz |
1.8V~3.3V
|
-40°C~+85°C
|
31fs Typ. @156.25MHz 3.3V LVPECL
|
Glitch-Free Switchover(@SYKB23F10G)
Ultra-low latency and skew |
|
||
|
|
DC~3.1GHz
|
LVDS
LVPECL LPHCSL LVCMOS |
10路差分
1路单端 |
LVDS
LVPECL LPHCSL LVCMOS 外部XTAL: 8~50MHz |
1.8V~3.3V
|
-40°C~+85°C
|
31fs Typ. @156.25MHz 3.3V LVPECL
|
Ultra-low latency and skew
|
|
||
|
DC~350MHz
|
LVCMOS
|
10
|
3 Input Reference (Two Differential
@DC~350Mhz/ One crystal@8~50Mhz) |
1.8V~3.3V
|
-40℃~+85℃
|
34 fs RMS (12kHz to 20MHz) typical
@LVCMOS 156.25MHz |
Glitch-Free Switchover Ultra-low latency and skew
|
|
||
|
1~333.33MHz
|
LPHCSL LVDS HCSL LVCMOS
|
4differential-pair outputs
2 LVCMOS clock outputs |
Internal Crystal: 50Mhz
|
1.8V~3.3V
|
-40℃~+85℃
|
236fs Typ. RMS(12KHz ~ 20MHz)@156.25MHz
|
Low power consumption: <150mw@
1.8V 100Mhz LP-HCSL outputs |
|
||
|
1~333.33MHz
|
LPHCSL LVDS HCSL LVCMOS
|
4differential-pair outputs
2LVCMOS clock outputs |
External Crystal: 8~50MHz or 1.22MHz~250MHz
|
1.8V~3.3V
|
-40℃~+85℃
|
236fs Typ. RMS(12KHz ~ 20MHz)@156.25MHz
|
Low power consumption: <150mw
@1.8V 100Mhz LP-HCSL outputs |
|
